Hydraulic Excavator
- Product Details
Our Hydraulic Excavator is designed for heavy-duty digging, lifting, and earthmoving tasks. Ideal for construction, mining, and demolition projects, it combines power, precision, and efficiency to get the job done faster and with more control.
| RSXE135D Hydraulic Excavator | |||
| 【Technical Specification】 | |||
| Product Name | Hydraulic Excavator | Operating Weight (kg) | 13200 |
| Model | RSXE135D | Bucket Capacity (m³) | 0.32-0.61 |
| [Engine] | |||
| Model | QSF 3.8 | Turbo | Yes |
| Empty In the Cold | Yes | Number of Cylinders | 4 |
| Electronic Fuel Injection | Yes | Maximum Torque/Speed (N.M/rpm) | 470/1300 |
| Four Stroke | Yes | Rated Power (kw/rmp) | 86/2200 |
| Water-cooling | Yes | Displacement(L) | 3.8 |
| 【Main Performance】 | |||
| Walking Speed (km/h) | 5.2/2.9 | Bucket Digging Force (KN) | 99.1 |
| Rotary Speed (r/min) | 11 | Arm Digging Force (KN) | 68 |
| Climbing Ability (dg） | 35 | Maximum Traction (KN) | 134 |
| Ground Pressure (Kpa) | 40.4 | ||
| 【Hydraulic System】 | |||
| Main Pump Rated Flow (L/min) | 125.4*2 | Rotary System Pressure (Map) | 25 |
| Main Safety Valve Pressure (Mpa) | 31.4 | Pilot System Pressure (Map) | 3.9 |
| Travel System Pressure (Mpa) | 34.4 | ||
| 【Oil Capacity】 | |||
| Fuel Tank Capacity (L) | 260 | Engine Oil Capacity (L) | 11 |
| Hydraulic Tank Volume (L) | 105 | ||
| 【Outline Dimension】 | |||
| Total Length (mm) | 7795 | Track Base (mm) | 2918 |
| Total Width (mm) | 2525 | Guage (mm) | 1990 |
| Total Height (mm) | 2880 | Counterweight Clearance (mm) | 931 |
| Table Width (mm) | 2490 | Minimum Ground Clearance (mm) | 466 |
| Track Shoe Length (mm) | 3648 | Minimum Turing Radius (mm) | 2325 |
| Overall Width of Chassis (mm) | 2490 | Track Height (mm) | 802 |
| Track Width (mm) | 500 | ||
| 【Scope of Work 】 | |||
| Maximum Digging Height (mm) | 8638 | Maximum Vertical Mining Depth (mm) | 4698 |
| Maximum Unloading Height (mm) | 6174 | Maximum Digging Radius (mm) | 8304 |
| Maximum Digging Depth (mm) | 5546 | Maximum Turing Radius (mm) | 2445 |
| Excavation Depth of 8 feet Level (mm) | 5335 | ||
| 【Standard】 | |||
| Boom Length (mm) | 4600 | Bucket Capacity (m³) | 0.52 |
| Arm Legth (mm) | 2520 | ||
OTHER EXCAVATOR
| Model | Specifciations |
| RD-0.6c | 1.Total Weight：13890kg |
| 2.Bucket capacity：0.6m³ | |
| 3.Dimensions： 7762*2510*2983mm | |
| 4.Speed：5.3km/h | |
| 5.Track shoe Length：3751mm | |
| 6.Track shoe Width：500mm | |
| 7.Fuel tank：280L | |
| 8.Hydraulik tank：165L | |
| 9.Max Digging Depth：5491mm | |
| 10.Max Digging Height：8679mm | |
| RD-0.9c | 1.Total weight：21900kg |
| 2.Bucket capacity：0.91m³ | |
| 3.Dimensions： 9586*2800*2891mm | |
| 4.Speed：5.2km/h | |
| 5.Track shoe Length：4165mm | |
| 6.Track shoe Width：600mm | |
| 7.Fuel tank：440L | |
| 8.Hydraulik tank：260L | |
| 9.Max Digging Depth：6672mm | |
| 10.Max Digging Height：9639mm | |
| RD-1c | 1.Total weight：22300kg |
| 2.Bucket capacity：1.0m³ | |
| 3.Dimensions： 7762*2510*2983mm | |
| 4.Speed：5.2km/h | |
| 5.Track shoe Length：4250mm | |
| 6.Track shoe Width：600mm | |
| 7.Fuel tank：420L | |
| 8.Hydraulik tank：260L | |
| 9.Max Digging Depth：6613mm | |
| 10.Max Digging Height：9639mm |
Key Features:
- Powerful Hydraulic System:
Provides exceptional digging force, lifting capacity, and smooth operation in tough conditions. - Versatile Attachments:
Compatible with a range of attachments (buckets, breakers, augers, etc.) for various tasks including digging, lifting, and demolition. - Efficient & Fuel-Efficient:
Engineered to offer high performance while maximizing fuel efficiency and reducing operating costs. - Durable Construction:
Built with high-strength materials to withstand heavy-duty tasks and harsh work environments. - Advanced Safety Features:
Equipped with safety features such as stable undercarriage design and operator protection systems. - Comfortable Operator Cabin:
Features an ergonomic, spacious cabin with excellent visibility and easy-to-use controls for enhanced comfort and safety.
