10 Tons Garbage Collection Truck
- Product Details
The Garbage Collection Truck is a robust, high-capacity vehicle designed for efficient waste collection and transportation. Featuring advanced compaction, versatile turnover devices, and reliable components, this truck is built for performance in any waste management scenario. With user-friendly controls and easy maintenance, it’s the ideal solution for urban and industrial waste collection.
SPECIFICATIONS
| Main Specification | |||
| Name | Compressing Garbage Collection | Announcement Series | 297 |
| Brand | ROADSKY | Colors | Different colors are options |
| Max. Weight | 18000 kg | Loading Capacity | 12 CBM |
| Rated Loading Capacity | 10000 kg | Net Weight | 10000 kg |
| Size | 8750×2500×3350 mm | Container Size | Custom-built |
| Rated carry capacity | 3 people | Front row cab | 2-3 people |
| ABS | Available | Loading use factor | 8 tons |
| Fuel | Diesel | Front/rear Suspension | 1450/2650; 1250/2650 mm |
| Quantity of bearings | 2 | Wheel Base: | 4700 mm |
| Quantity of tyres | 6 | Tyres’size | 10.00-20 18PR,10.00R20 18PR,11.00-20 16PR, |
| Front wheel tread | 1940 mm | rear wheel tread | 1860 mm |
| Max. Bearing loading capacity | 6500/11500 kg | Max. Speed | 90 km/h |
| Chassis | ||||
| Model of Chassis | EQ | Factory | Dongfeng | |
| Tyres’ quantity | 6 | Spring quantity | 8/9+7,8/10+7,3/4+3,9/12+10,8/10+8,7/9+6,11/11+10 | |
| Tyres’size | 10.00-20 18PR,10.00R20 18PR | Turning way | Steering wheel | |
| Front Wheel Tread | 1810,1940,1780 | Rear wheel tread | 1800,1860,1750 | |
| Fuel | Diesel | Series | 302 | |
| Emission | Euro V | |||
| Engine model | Engine factory | displacement | Rated power | |
| ISB190 50 | Commins | 5900 ML | 140 KW | |
| Installation description | The container is made from high-quality WUGANG carbon steel, with 4mm side steel and 5mm reinforced base steel. It features two-direction compression and an easy-to-clean open drainage tank. The stuffer uses a thickened axial ratio structure, while key components (hydro-cyclinder, valves, etc.) are sourced from top Chinese brands. The system offers both manual and electric controls, with two electric controllers and cab control. It includes two turnover devices: a garbage hanging barrel and a dustpan bucket turnover device for versatile waste handling. | |||
